Eaton XTCE012B10TD 3-Pole Contactor | 12A | 24VDC Coil | MSAA276845

Eaton XTCE012B10TD | 3-Pole Contactor | 12A | 24VDC Coil | MSAA276845 | IEC Rated | New

The Eaton XTCE012B10TD (catalog ref: MSAA276845) is a compact, high-performance IEC-rated contactor designed to deliver reliable switching and motor control in industrial automation, HVAC, and machinery applications. Part of Eaton’s industry-proven XT series, this contactor supports 3-phase systems and is rated for 12A AC-3 at 400V, making it ideal for controlling small motors and resistive loads up to approximately 5.5 kW.

This model features a 24VDC coil, enabling low-voltage control logic compatibility, especially in environments where noise immunity and safe signaling are critical. The XTCE012B10TD is equipped with a 1 Normally Open (1NO) auxiliary contact for status signaling, interlocking, or secondary circuit control.

Built for performance and ease of integration, the XT series offers DIN rail and panel mounting, finger-safe terminals, and compatibility with a full range of accessories such as overload relays, mechanical interlocks, and suppressor modules. This model is compliant with IEC 60947, CE, UL, and CSA standards.

🔧 Key Features & Specifications:

• Manufacturer: Eaton
• Model Number: XTCE012B10TD
• Catalog Reference: MSAA276845
• Series: XT IEC Contactor Series
• Number of Poles: 3
• AC-3 Rating: 12 Amps at 400V
• Motor Power Rating: Up to 5.5 kW @ 400V
• Control Voltage: 24VDC coil
• Auxiliary Contacts: 1 Normally Open (1NO)
• Coil Consumption: Low power draw with DC economy circuit
• Mounting: DIN rail or screw mounting
• Terminal Type: Finger-safe spring or screw terminals
• Mechanical Life: Over 10 million operations
• Electrical Life: Up to 1 million operations (AC-3 duty)
• Certifications: IEC 60947-4-1, UL, CSA, CE marked
• Operating Temperature: -25°C to +60°C
• Condition: Brand New, Unused

Compact and durable, the XTCE012B10TD is a trusted solution for OEMs, panel builders, and electrical maintenance professionals seeking high-efficiency, long-life contactors for control cabinets and field installations.
